QOU2301042 - Square D QOU 30A 2 Pole 120/240V Miniature Circuit Breaker with Shunt Trip 10kA

QOU2301042

QOU2301042 is a Square D QOU Series miniature circuit breaker featuring a 30A amperage rating, 2-pole configuration, and 120/240V AC voltage compatibility. This breaker is designed for reliable protection in commercial and industrial applications. The QOU2301042 is a bolt-on mounting type, equipped with a shunt trip for remote operation, and offers a 10kA interrupt rating at 240V AC. It features a thermal-magnetic trip unit for precise overcurrent protection and is suitable for use in QOU series panels. The breaker is compact, with a width of 1.5 inches, and is built to meet industry standards for safety and performance.

• Part Number: QOU2301042
• Manufacturer: Square D (Schneider Electric)
• Series/Frame: QOU
• Amperage Rating: 30A
• Number of Poles: 2 Pole
• Voltage Rating: 120/240V AC
• Interrupt Rating: 10kA @ 240V AC
• Mounting Type: Bolt-On
• Shunt Trip: Yes
• Trip Unit: Thermal-Magnetic
• Width: 1.5 inches
• Weight: 1.00 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOU2301042
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOU Series
• Type : QOU
• Voltage : 240
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 78590158603
• GTIN : 00785901586036
• Country of Origin : Mexico
• Dimensions : 4.05 in (102.87 mm) x 2.25 in (57.15 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
• Weight : 1.06
• Wire Size : AWG 14...AWG 2 aluminium/copper
