QOB260H - Square D QO Miniature Circuit Breaker 60A 2 Pole 120/240V Bolt-On

QOB260H

QOB260H is a Square D QO series miniature circuit breaker designed for reliable protection in residential and light commercial applications. This 60A, 2-pole breaker features a bolt-on mounting style and is rated for 120/240V AC systems. Engineered for use in QO load centers, the QOB260H provides dependable overcurrent protection with a 10kA interrupt rating. It is calibrated for use at 40¡C and supports wire sizes #8 to #2 AWG (Al/Cu). The breaker is UL and CSA listed for safety and compliance.

• Part Number: QOB260H
• Manufacturer: Square D
• Series: QO
• Amperage: 60A
• Poles: 2
• Voltage: 120/240V AC
• Mounting Type: Bolt-On
• Interrupt Rating: 10kA
• Wire Size: #8 to #2 AWG (Al/Cu)
• Calibration: 40¡C
• Frequency: 50/60 Hz
• Certifications: UL, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOB260H
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOB Series
• Type : QOB
• Voltage : 120/240VAC
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Pressure Plate
• MCM Size : Min. Wire Size 8 AWG (Cu/Al) Max. Wire Size 2 AWG (Cu/Al)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 78590133546
• GTIN : 00785901335467
• Country of Origin : Mexico
• Dimensions : 3.1 in (79 mm) x 1.5 in (38 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 0.71
• Standards : CSA, UL Listed
• Certification : UL Listed
