QOB21251021 - Square D 125A 120/240V 2 Pole Thermal Magnetic Circuit Breaker QOB Series Bolt-On

QOB21251021

QOB21251021 is a Square D 2 pole thermal magnetic circuit breaker rated for 125 amps and 120/240 volts AC with bolt-on mounting.This QOB Series molded case circuit breaker features long-time and instantaneous trip functions, a 10kA interrupting rating at 120/240VAC, and is UL and CSA certified. It is designed for use in QOB Series load centers with box lug terminal connections supporting AWG 4 to AWG 2/0 copper or aluminum wire.

• Amperage: 125A
• Voltage: 120/240VAC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupting Rating: 10kAIC at 120/240VAC
• Series/Frame: QOB
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous
• Certifications: UL, CSA, RoHS, REACh, HACR
• Phase: 1
• Terminal Connection: Box Lugs
• Wire Gauge: AWG 4 to AWG 2/0 Copper/Aluminum
• Temperature Rating: 40 ¡C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOB21251021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOB Series
• Type : QOB
• Voltage : 120/240VAC
• Amperage : 125
• Phase : 1
• Poles : 2
• AIC rating : 10kA@120V
• Connection : Bolt-On
• Functions : Long-Time and Instantaneous Trip
• Terminal Connection : Pressure Plate
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901120650
• GTIN : 00078590172950
• Country of Origin : Mexico
• Dimensions : 3.5 in (89 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 1.02
• Standards : CSA, UL Listed
• Certification : UL Listed
• Wire Size : AWG 4 to AWG 2/0, Copper/Aluminum
