QO360VH - Square D 60A 3 Pole 120/240VAC Circuit Breaker Plug-In QO Series 22kA Interrupt Rating

QO360VH

QO360VH is a Square D 3 pole circuit breaker rated for 60 amps and 120/240VAC voltage, designed for reliable circuit protection.This QO series thermal magnetic molded case circuit breaker features a plug-in mounting type, 22kA interrupting rating at 120/240VAC, and long time plus instantaneous trip functions. It is UL and CSA certified, compatible with QO load centers and NQ panelboards, and supports AWG 8 to AWG 2 copper or aluminum wiring.

Key Specifications
• Manufacturer: Square D
• Series: QO
• Amperage: 60A
• Voltage: 120/240VAC
• Poles: 3
• Mounting Type: Plug-In
• Interrupt Rating: 22kA at 120/240VAC
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
• Certifications: UL, CSA
• Terminal Connection: Box Lug
• Compatible Wire Gauge: AWG 8 to AWG 2 Copper/Aluminum
• Application: For use with QO Load Centers and NQ Panelboards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QO360VH
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QO Series
• Type : QO
• Voltage : 240
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 22kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901060222
• GTIN : 00785901060222
• Country of Origin : Mexico
• Dimensions : 3.1 in (79 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 1.087
• Certification : UL Listed
• Wire Size : AWG 8 to AWG 2 Copper/Aluminum
