QDA32110 - Square D PowerPact Q 3-Pole 110A 240V 25kA Thermal Magnetic Molded Case Circuit Breaker

QDA32110

QDA32110 is a 3-pole, 110A, 240V AC molded case circuit breaker designed for reliable power distribution and overcurrent protection in commercial and industrial applications. This Square D PowerPact Q series breaker features a thermal-magnetic trip unit, 25kA interrupt rating, and is suitable for I-Line panelboards and switchboards. It provides dependable protection for AC systems and is UL 489 Listed, CSA, and IEC certified.

• Part Number: QDA32110
• Manufacturer: Square D
• Series: PowerPact Q
• Amperage: 110A
• Voltage: 240V AC
• Poles: 3
• Interrupt Rating: 25kA
• Mounting Type: I-Line
• Trip Unit: Thermal-Magnetic
• Continuous Current Rating: 80%
• Certifications: UL 489 Listed, CSA, IEC
• Application: Power Distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QDA32110
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : QDA
• Voltage : 240
• Amperage : 110
• Phase : 3
• Poles : 3
• AIC rating : 25kA@240V
• Connection : Plug In Panelboard
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 250A/QD
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 4 AWG Max. Wire Size 300 MCM
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901603566
• GTIN : 00785901603566
• Country of Origin : Mexico
• Dimensions : 6.47 in (164.34 mm) x 4.5 in (114.3 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
• Weight : 6.669
• Panel Type : I Line Panelboards
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
• Certification : UL, CSA, NOM
