QDA32070 - Square D 70A 240V 3-Pole Thermal Magnetic Molded Case Circuit Breaker I-Line

QDA32070

QDA32070 is a 3-pole, 70 amp, 240 volt thermal magnetic molded case circuit breaker from Square D designed for reliable power distribution protection.This Square D QDA32070 circuit breaker features a 3-pole configuration with a 70 ampere rating and 240 volts AC voltage rating. It uses a thermal magnetic trip unit providing long-time and instantaneous protection. The breaker mounts via an I-Line style plug-in connection and has a 25kA interrupting rating at 240V AC. It is UL, CSA, and IEC certified and built on the QDA frame series for industrial applications.

Key Specifications
• Amperage: 70 Amps
• Voltage: 240 Volts AC
• Poles: 3
• Mounting Type: I-Line Style Plug-In
• Interrupting Rating: 25kA at 240V AC
• Frame Type: QDA Series
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Certifications: UL, CSA, IEC
• Connection Type: Load side lug
• Dimensions (LxWxH): 3.93 x 4.5 x 6.47 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QDA32070
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : QDA
• Voltage : 240
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 25kA@240V
• Connection : Plug In Panelboard
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 250A/QD
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 4 AWG Max. Wire Size 300 MCM
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901475835
• GTIN : 00785901475835
• Country of Origin : Mexico
• Dimensions : 6.47 in (164.34 mm) x 4.5 in (114.3 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
• Weight : 6.66
• Panel Type : I Line Panelboards
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
• Certification : UL, CSA, NOM
• Wire Size : AWG 4, 300KCmil Aluminum/Copper
