Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
Q2L3225H
Q2L3225H is a 3 pole, 225 amp, 240 volt thermal magnetic molded case circuit breaker from Square D's Q2 Series designed for reliable power distribution protection.This Type Q2L breaker features a high interrupting rating of 22kA at 240V, feed-thru line in/line out lug terminals, and includes long time and instantaneous trip functions. It is engineered for 3-phase AC systems with a Q2L frame and non-interchangeable trip unit.
- Key Specifications
- Amperage: 225A
- Voltage: 240V AC
- Number of Poles: 3
- Interrupting Rating: 22kA at 240V
- Series/Frame: Q2L
- Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trips
- Mounting Type: Feed-Thru Lug Terminals (Line & Load Side)
- Voltage Type: AC
- Non-Interchangeable Trip
- Certifications: UL Listed
Specifications
- Part Number: Q2L3225H
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Q2 Series
- Type : Q2L
- Voltage : 240
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 22kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 794518212139
- Weight : 4
- Certification : UL, CSA
