Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
PJA36060CU31A
PJA36060CU31A is a Schneider Electric PowerPacT P series molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This breaker features a 600A current rating, 3-pole configuration, and is rated for 600VAC with a 25kA interrupting rating at 600VAC. It is equipped with the Micrologic 3.0 electronic trip unit for precise protection and monitoring. The breaker is designed for I-Line busbar mounting and is suitable for use as a main panel disconnect in control panels. The PowerPacT P series offers standardized mounting holes, handle locations, and trim dimensions for easy integration and design consistency. It supports a wide range of accessories and is certified for global applications with UL 489, CSA NMX, and IEC standards. The breaker is built for 100% continuous current operation and is constructed with environmentally responsible packaging using recycled cardboard.
- Part Number: PJA36060CU31A
- Manufacturer: Schneider Electric
- Series: PowerPacT P
- Current Rating: 600A
- Voltage Rating: 600VAC
- Poles: 3
- Interrupting Rating: 25kA @ 600VAC
- Mounting Type: I-Line Busbar
- Breaker Type: Molded Case
- Actuator Type: Toggle
- Continuous Current: 100%
- Trip Unit: Micrologic 3.0
- Certifications: UL 489, CSA NMX, IEC
Specifications
- Part Number: PJA36060CU31A
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : PJA
- Voltage : 600
- Amperage : 600
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : I-Line Style Plug-In
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : AL800M23K
- Frame Size : P Frame
- Temp Rating : 13-158 °F (-25-70 °C)
- Protection : Solid State
Product Data
- UPC : 785901433293
- GTIN : 00785901433293
- Country of Origin : Mexico
- Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
- Weight : 32
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
