PJA36025CU44A - Schneider Electric PowerPact P 250A 3-Pole 600V Circuit Breaker

PJA36025CU44A

PJA36025CU44A is a 3-pole molded case circuit breaker manufactured by Schneider Electric, rated for 250 amperes at 600 volts AC. This PowerPact P series breaker features I-Line plug-in mounting and is equipped with Micrologic 6.0A trip unit technology for reliable protection and monitoring of industrial power distribution systems. The breaker delivers advanced protection with solid-state sensing and is designed for use in panelboards and distribution equipment requiring dependable overcurrent protection.

• Amperage Rating: 250A
• Voltage Rating: 600VAC
• Poles: 3
• Series: PowerPact P
• Mounting: I-Line Plug-In
• Trip Unit: Micrologic 6.0A
• Interrupt Rating: 65kA at 480V
• Frame Size: 36
• Molded Case Construction
• Thermal-Magnetic Protection

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PJA36025CU44A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PJA
• Voltage : 600
• Amperage : 250
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Terminal Connection : AL800M23K
• Frame Size : P Frame
• Temp Rating : 13-158 °F (-25-70 °C)
• Protection : Solid State

Product Data

• UPC : 060648628578
• GTIN : 03606486285787
• Country of Origin : United States
• Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
