PGA36040CU33A - Square D 400A 600V 3 Pole I-Line Circuit Breaker 35kA Interrupt Rating

PGA36040CU33A

PGA36040CU33A is a Square D 3 pole, 400 amp, 600 volt I-Line style circuit breaker designed for reliable power distribution protection.This molded case circuit breaker features a 35kA interrupt rating at 480V, suitable for industrial and commercial applications requiring high interrupt capacity and robust performance. It mounts with an I-Line style frame and provides dependable trip unit protection.

• Amperage: 400A trip, 800A frame
• Voltage Rating: 600V
• Poles: 3
• Mounting Type: I-Line
• Interrupt Rating: 35kA at 480V
• Series/Frame: PGA
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PGA36040CU33A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PGA
• Voltage : 600
• Amperage : 400
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Frame Size : P Frame
• Protection : Solid State

Product Data

• Country of Origin : United States
• Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
