Reference images. Contact us for photos of the available unit.
Product Description & Specifications
Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.
- Manufacturer
- Square D
- Sub-Category
- Molded Case
- Series
- PowerPact P-Frame
- Frame
- PEF
- Rated current
- 2000
- Voltage
- 600V
- Poles
- 3
- Phases
- 3
- Interrupting rating
- 100kA@480V
- Trip functions
- LIG - Long-Time, Instantaneous and Ground Fault
- Protection
- Solid State
- Connection
- Bolt-On
- Standards
- UL 489 listed, CSA certified, IEC 60947-2 compliant
- Weight
- 90 lb
Product description & additional details
PEF362000LIG
PEF362000LIG is a PowerPact P-frame molded case circuit breaker manufactured by Schneider Electric / Square D. It is a 3-pole, 2000 A, 600 V AC breaker equipped with an LIG Micrologic trip unit, providing long-time, instantaneous, and ground-fault protection. The PEF362000LIG is engineered for heavy-duty commercial and industrial distribution systems requiring high-capacity, adjustable electronic protection.
- Manufacturer: Schneider Electric / Square D
- Series: PowerPact P-Frame
- Type: Electronic Trip Molded Case Circuit Breaker
- Poles: 3
- Amperage Rating: 2000 A
- Voltage Rating: 600 V AC
- Trip Unit: LIG Micrologic (Long-Time, Instantaneous, Ground-Fault)
- Interrupting Rating: Up to 100 kA at 480 V AC (depending on configuration)
- Mounting: Bolt-on / panel or switchboard
- Application: High-capacity power distribution and protection
- Standards: UL 489 listed, CSA certified, IEC 60947-2 compliant
Specifications
- Part Number: PEF362000LIG
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : PowerPact P-Frame
- Type : PEF
- Voltage : 600
- Amperage : 2000
- Phase : 3
- Poles : 3
- AIC rating : 100kA@480V
- Connection : Bolt-On
- Functions : LIG - Long-Time, Instantaneous and Ground Fault
- Protection : Solid State
Product Data
- Weight : 90 lb
- Standards : UL 489 listed, CSA certified, IEC 60947-2 compliant
Return eligibility: what to know before ordering
Return requests must be made within 30 days of shipping and require authorization. Used, installed, energized, or tested items are not eligible. A restocking fee of up to 35% may apply. Review the full policy before purchase.
Product-specific restrictions apply. International orders are non-cancellable and non-refundable under the policy.
Warranty supplied by Essential Electric
Warranty coverage is provided by Essential Electric, subject to the product and policy terms. Essential Electric is an independent supplier. Surplus or discontinued inventory may not qualify for the original manufacturer’s warranty.
