PDG23M0080TFFL - Eaton 80 Amp 600VAC 3 Pole Power Defense Circuit Breaker Frame 2 Thermal Magnetic

PDG23M0080TFFL

PDG23M0080TFFL is an Eaton Power Defense 3 pole molded case circuit breaker rated for 80 amps and 600 volts AC.This circuit breaker features a thermal magnetic trip unit with long time and instantaneous trip functions, a bolt-on mounting type, and a 65kA interrupting rating at 480VAC. It is globally rated, Frame 2, and compliant with UL, CSA, IEC, CCC, and RoHS standards.

• Manufacturer: Eaton
• Series: Power Defense (PDG2 Frame)
• Amperage: 80A
• Voltage: 600VAC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupting Rating: 65kA at 480VAC
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous
• Terminal Connection: Standard Load Side Lug
• Certifications: UL, CSA, IEC, CCC, RoHS
• Phase: 3
• Type: Complete Breaker

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG23M0080TFFL
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 078667986285
• GTIN : 00786679862858
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
• Weight : 4.0586 lb
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 509
