PDG21G0040TFFJ - Eaton 40A 600V 1-Pole Molded Case Circuit Breaker Frame 2 Thermal Magnetic

PDG21G0040TFFJ

PDG21G0040TFFJ is a Eaton Power Defense molded case circuit breaker designed for reliable circuit protection in industrial and commercial applications.This single-pole breaker features a 40 ampere rating, 600 volt maximum voltage, and a 35kA interrupting rating at 480VAC. It uses a thermal magnetic trip unit with long-time and instantaneous functions for precise protection. The breaker has a Frame 2 size and a feed-thru connection type, suitable for panel mounting. It meets multiple certifications including UL, CSA, IEC, CCC, and CE.

• Amperage: 40A
• Voltage: 600VAC, 250VDC max
• Poles: 1
• Interrupt Rating: 35kAIC at 480VAC
• Frame Type: Frame 2 (PDG series)
• Trip Unit: Thermal Magnetic (LI - Long-Time and Instantaneous)
• Mounting Type: Panel Mount
• Connection Type: Feed-Thru
• Phase: Single Phase
• Protection: Thermal Magnetic
• Certifications: UL, CSA, IEC, CCC, CE
• Dimensions: 5.75" H x 4.12" W x 3.5" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG21G0040TFFJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 40
• Phase : 1
• Poles : 1
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679254691
• GTIN : 00786679000000
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 35.1 mm (Length/Depth x Height x Width)
• Weight : 4.55143
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
