Product Info
- Manufacturer: Cutler Hammer
- Sub-Category: Fusible
Description
P3F366RN
P3F366RN is a 600 Amp, 3-pole fusible bus plug from Eaton's Pow-R-Way III series designed for 277/480 Volt busway systems. This fusible plug-in unit features R class fuses and a 100% neutral for reliable protection and performance in low voltage power distribution. It is UL 857 listed and certified by ANSI, CSA, and IEEE, ensuring compliance with industry standards. The unit measures 48.9 inches in height, 10.59 inches in length, and 26.31 inches in width, weighing approximately 82 pounds. It provides integral grounding with 50% grounding options and is suitable for busway applications requiring fusible protection.
- Amperage: 600A
- Voltage: 277/480V
- Poles: 3
- Fuse Type: R Class
- Neutral: 100% Neutral
- Mounting Type: Plug-in Unit
- Series/Frame: Pow-R-Way III
- Certifications: UL 857, ANSI, CSA, IEEE
- Grounding: 50% Integral Grounding
- Dimensions (HxLxW): 48.9 x 10.59 x 26.31 inches
- Weight: 82 lbs
Specifications
- Part Number: P3F366RN
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Bus Plug
- Item Subcategory : Fusible
- Family : Pow-R-Way III
- Type : P3F
- Voltage : 600
- Amperage : 100
- Phase : 3
- AIC rating : 200kA@600V
- Fuse Class : R
Product Data
- UPC : 786683020855
- GTIN : 00786683020855
- Country of Origin : United States
- Dimensions : 10.59 in x 48.9 in x 26.31 in (Length/Depth x Height x Width)
- Weight : 82 lb
- Certification : ANSI CSA Certified IEEE Certified UL 857
