NGB2B080 - Siemens 80A 600V 2 Pole Bolt-On Thermal Magnetic Circuit Breaker NGB Frame

NGB2B080

NGB2B080 is a Siemens 80 Amp, 600 Volt, 2 Pole bolt-on circuit breaker designed for reliable circuit protection.

This Siemens NGB series circuit breaker features a thermal magnetic trip unit and bolt-on mounting type. It has a frame type NGB and is rated for 80 amps with a maximum voltage of 600V AC. The breaker offers interrupting ratings of 100,000 A at 240V AC and 25,000 A at 480V AC, ensuring high fault current interruption capability. It is UL489 certified and suitable for panel board applications requiring a compact 2-inch wide breaker.

• Amperage: 80A
• Voltage: 600V AC
• Poles: 2
• Mounting Type: Bolt-On
• Frame Type: NGB
• Interrupting Rating: 100,000 A @ 240V AC
• Interrupting Rating: 25,000 A @ 480V AC
• Trip Unit: Thermal Magnetic
• Certification: UL489
• Dimensions: 2" W x 4.5" H x 3.3" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: NGB2B080
• Manufacturer : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : VL Series
• Type : NGB
• Voltage : 600
• Amperage : 80
• Phase : 1
• Poles : 2
• AIC rating : 25kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : GG Frame
• Temp Rating : -13¡F-158¡F
• Protection : Thermal Magnetic

Product Data

• UPC : 783643553347
• GTIN : 00783643553347
• Country of Origin : Mexico
• Weight : 1.863
• Certification : UL, IEC
