Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
NGB2B050
NGB2B050 - Siemens 2-pole, 50A molded case circuit breaker designed for reliable overcurrent protection in industrial applications.The Siemens NGB2B050 features a NGB frame, thermal-magnetic trip unit, and bolt-on mounting for secure installation in panelboards. It supports maximum voltage of 600Y/347V AC with verified interrupting ratings including 25kA at 480Y/277V and 14kA at 600Y/347V per UL489 standards.Key Specifications
- Amperage: 50A
- Voltage: 600Y/347V AC
- Poles: 2
- Mounting Type: Bolt-On
- Frame/Series: NGB
- Trip Unit: Thermal-Magnetic
- Interrupt Rating: 25kA @ 480Y/277V; 14kA @ 600Y/347V
- Certifications: UL489
- Wire Size: #14 to 2/0 AWG (Al/Cu)
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: NGB2B050
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : VL Series
- Type : NGB
- Voltage : 600
- Amperage : 50
- Phase : 1
- Poles : 2
- AIC rating : 25kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : GG Frame
- Temp Rating : -13¡F-158¡F
- Protection : Thermal Magnetic
Product Data
- UPC : 783643553316
- GTIN : 00783643553316
- Country of Origin : Mexico
- Weight : 1.863
- Certification : UL, IEC
