MXF36700 - Square D PowerPact M Frame 700 Amp 3 Pole Molded Case Circuit Breaker 600 VAC

MXF36700

MXF36700 is a Square D PowerPact M Frame molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This 3-pole breaker is rated for 700 amps and 600 VAC, featuring a robust design suitable for demanding applications. The MXF36700 is built to meet UL 489 standards and is engineered for unit mount installation, ensuring compatibility with a wide range of panelboards and switchgear. The MXF36700 offers a high interrupt rating, providing dependable short-circuit protection. Its M Frame construction supports efficient thermal and magnetic tripping performance, making it ideal for use in environments where safety and reliability are critical. The breaker is designed for easy installation and maintenance, with a plug-in style connection for quick replacement.

• Part Number: MXF36700
• Manufacturer: Square D
• Series/Frame: PowerPact M Frame
• Amperage: 700 Amp
• Voltage: 600 VAC
• Poles: 3 Pole
• Mounting Type: Unit Mount
• Interrupt Rating: 100 kA @ 480 VAC
• Interrupt Rating: 25 kA @ 600 VAC
• Interrupt Rating: 65 kA @ 240 VAC
• UL Listing: UL 489
• Connection: Plug-In

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: MXF36700
• Manufacturer : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Micrologic
• Type : MXF
• Voltage : 600
• Amperage : 700
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Protection : Solid State

Product Data

• Dimensions : Depth 8.05 in (204.47 mm) Width 8.27 in (210.06 mm) Height 12.86 in (326.64 mm)
• Weight : 50
