MG24532 - Schneider Electric 1 Amp 3 Pole Molded Case Circuit Breaker DIN Rail Mount

MG24532

MG24532 is a 1 Amp, 3 Pole molded case circuit breaker from Schneider Electric designed for DIN rail mounting.MG24532 features a D curve trip unit and is rated for 480Y/277 V AC operation with a 5 kA interrupt rating. It complies with EN/IEC 60947-2 standards and supports padlockable operation with tunnel type terminals suitable for wire sizes AWG 14 to AWG 4. This breaker offers high durability with 20,000 mechanical and 10,000 electrical cycles.

• Amperage: 1 Amp
• Poles: 3
• Mounting Type: DIN Rail
• Voltage Rating: 480Y/277 V AC
• Interrupt Rating: 5 kA
• Trip Unit: D Curve
• Standards: EN/IEC 60947-2
• Terminal Type: Tunnel type, top or bottom
• Wire Size Range: AWG 14 to AWG 4
• Padlockable: Yes
• Mechanical Life: 20,000 cycles
• Electrical Life: 10,000 cycles

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: MG24532
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Multi9
• Type : MG
• Voltage : 240
• Amperage : 1
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Dimensions : 3.2 in (81 mm) x 2.1 in (54 mm) x 2.9 in (73 mm) (Height x Width x Depth)
• Weight : 0.79
