Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG24526
MG24526 is a Square D 2-pole molded case circuit breaker rated for 25 amps and 240 volts with a 10kA interrupting capacity. It features bolt-on mounting for secure installation.
This circuit breaker provides reliable thermal magnetic trip protection and is designed for use in a variety of electrical distribution applications. It meets UL 489 and CSA C22.2 No.5 standards and is suitable for 50/60 Hz systems. The breaker is part of the Multi 9 series and offers a D curve trip characteristic for current limiting protection.
- Key Specifications
- Amperage: 25A
- Voltage Rating: 240V AC
- Number of Poles: 2
- Mounting Type: Bolt-On
- Interrupt Rating: 10kA @ 240V
- Trip Unit: Thermal Magnetic
- Series/Frame: Multi 9
- Standards: UL 489, CSA C22.2 No.5
- Frequency: 50/60 Hz
- Trip Curve: D Curve
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: MG24526
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 240
- Amperage : 25
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 785901400601
- Dimensions : 3.2 in (81 mm) x 1.4 in (36 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.52
