MG24525 - Schneider Electric 20A 2 Pole DIN Rail Circuit Breaker 480Y/277V D Curve

MG24525

MG24525 is a Schneider Electric 2 pole, 20 amp DIN rail mount circuit breaker designed for 480Y/277 Volt applications with a D curve trip unit.This molded case circuit breaker features a thermal magnetic trip mechanism, suitable for protecting electrical circuits with a 6 kA interrupt rating at 480 VAC. It complies with EN/IEC 60947-2 standards and offers reliable performance with up to 20,000 mechanical cycles. The breaker supports tunnel type terminals for flexible wiring and is padlockable for safety.

• Amperage: 20 Amps
• Voltage Rating: 480Y/277 VAC
• Poles: 2
• Mounting Type: DIN Rail
• Interrupt Rating: 6 kA at 480 VAC
• Trip Unit: Thermal Magnetic, D Curve
• Standards: EN/IEC 60947-2
• Terminal Type: Tunnel type, top or bottom
• Padlockable for safety
• Mechanical Life: 20,000 cycles
• Manufacturer Series: Multi9 C60 UL1077

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: MG24525
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 240
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• GTIN : 00785901881254
• Dimensions : 3.2 in (81 mm) x 1.4 in (36 mm) x 2.9 in (73 mm) (Height x Width x Depth)
• Weight : 0.507
