Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG24521
MG24521 is a 2 pole, 8 amp, 480Y/277V supplementary protector circuit breaker from the Square D Multi9 series, designed for reliable branch circuit protection in commercial and industrial applications. This breaker features a D trip curve for high inrush load protection and is UL1077 listed for supplementary protection. The MG24521 is a compact, bolt-on miniature circuit breaker suitable for DIN rail or panel mounting. It offers a 10kA interrupting rating at 240V and a 5kA rating at 480Y/277V, making it ideal for a wide range of electrical distribution needs. The breaker is designed for use in control panels, machinery, and equipment requiring supplementary overcurrent protection.
- Part Number: MG24521
- Manufacturer: Square D
- Series: Multi9
- Type: Supplementary Protector
- Number of Poles: 2
- Rated Current: 8A
- Rated Voltage: 480Y/277V
- Mounting Type: Bolt-On / DIN Rail
- Interrupting Rating: 10kA @ 240V, 5kA @ 480Y/277V
- Frame: C60
- Trip Curve: D
- Certifications: UL1077, IEC 60947-2
Specifications
- Part Number: MG24521
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 240
- Amperage : 8
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Dimensions : 3.2 in (81 mm) x 1.4 in (36 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.5
