Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG24520
MG24520 is a 2-pole, 6A, 240V thermal magnetic circuit breaker from Square D, designed for reliable protection in commercial and industrial applications. This bolt-on mount breaker features a robust design and is suitable for use in a variety of electrical panels. The MG24520 offers a 10 kA interrupting rating at 120/240 VAC and 5 kA at 277 VAC or 480 VAC Star/277 VAC, ensuring dependable performance under fault conditions. It is UL 1077 and CE certified, supporting wire sizes from 14 to 4 AWG copper. The breaker is current limiting and features a D-curve trip unit for enhanced protection.
- Part Number: MG24520
- Manufacturer: Square D
- Amperage: 6A
- Voltage: 240V (also rated for 120/277/480V)
- Poles: 2
- Mounting Type: Bolt-On
- Interrupt Rating: 10 kA at 120/240 VAC, 5 kA at 277/480 VAC
- Series/Frame: C60
- Trip Unit: D-Curve, Thermal Magnetic
- Wire Size: 14 to 4 AWG (Copper)
- Certifications: UL 1077, CE
- Application: Supplementary Protection
Specifications
- Part Number: MG24520
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 240
- Amperage : 6
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 785901881186
- Dimensions : 3.2 in (81 mm) x 1.4 in (36 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.51
