Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG24518
MG24518 is a Square D Multi9 miniature circuit breaker designed for reliable overcurrent protection in industrial and commercial applications. This 2-pole, 3-ampere unit operates at 480Y/277 volts AC with a D-curve trip characteristic and 5kA interrupt rating at rated voltage. The bolt-on mounting design integrates seamlessly into Multi9 distribution panels and enclosures. UL1077 listed and CSA certified, the MG24518 delivers consistent performance across standard North American electrical systems.
- Manufacturer: Square D (Schneider Electric)
- Poles: 2
- Amperage: 3 Amps
- Voltage: 480Y/277V AC
- Interrupt Rating: 5kA
- Trip Curve: D Curve
- Mounting: Bolt-On
- Series: Multi9 C60
- Rated Insulation Voltage: 500V AC
- Certifications: UL1077, CSA
Specifications
- Part Number: MG24518
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : MG
- Voltage : 240
- Amperage : 3
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 785901881162
- Dimensions : 3.2 in (81 mm) x 1.4 in (36 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.52
