Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG24509
MG24509 is a single-pole molded case circuit breaker from Schneider Electric designed for supplementary protection in AC and DC applications. This Din rail mount breaker features thermal-magnetic trip technology with a D-curve characteristic and is rated for 20 amperes at 277 volts. MG24509 delivers reliable overcurrent and short-circuit protection with a 10 kA breaking capacity at 240V AC, making it suitable for industrial and commercial electrical distribution systems. The breaker is UL1077 certified and engineered for demanding environments requiring consistent performance and safety.
- Amperage: 20A
- Voltage: 277V AC
- Poles: 1
- Mounting: Din Rail
- Trip Unit Technology: Thermal-Magnetic
- Curve Code: D
- Breaking Capacity: 10 kA Icu at 240V AC
- Certification: UL1077
- Connection Type: Bolt-On
- Series: Multi9 C60
- Terminal Type: Tunnel type terminal top or bottom
- Wire Range: AWG 14 to AWG 4 rigid
Specifications
- Part Number: MG24509
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : MG
- Voltage : 240
- Amperage : 20
- Phase : 1
- Poles : 1
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Dimensions : 3.2 in (81 mm) x 0.7 in (18 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.26
