Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG24507
MG24507 is a 1-pole, 13 amp, 240V bolt-on circuit breaker from the Multi9 family, designed for reliable thermal magnetic protection in a variety of electrical applications. This breaker features a D curve trip unit and is suitable for use as a supplementary protector in appliances and equipment where branch circuit protection is provided or not required. The MG24507 is a compact, DIN rail mount circuit breaker with a 10kA interrupt rating at 240V. It is engineered for use in both AC and DC circuits, with a high amp trip setting of 182A and a low amp trip setting of 130A. The breaker is rated for 50/60 Hz operation and is designed to meet UL1077 standards for supplementary protectors.
- Part Number: MG24507
- Manufacturer: Schneider Electric
- Series: Multi9
- Amperage: 13A
- Voltage: 240V
- Poles: 1
- Mounting Type: Bolt-On / DIN Rail
- Interrupt Rating: 10kA @ 240V
- Protection Type: Thermal Magnetic
- Curve Type: D
- Standards: UL1077
- Application: Supplementary Protector
Specifications
- Part Number: MG24507
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : MG
- Voltage : 240
- Amperage : 13
- Phase : 1
- Poles : 1
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Dimensions : 3.2 in (81 mm) x 0.7 in (18 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.26
