Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG24500
MG24500 is a 1-pole, 1 amp, 240V bolt-on circuit breaker from the Square D Multi9 MG series, designed for reliable protection in commercial and industrial applications. This Square D MG24500 circuit breaker features a thermal magnetic trip unit and a D-curve response, making it suitable for loads with high inrush currents. The bolt-on mounting ensures secure installation, and the breaker is UL listed and CSA certified for safety and compliance.
- 1 pole
- 1 ampere current rating
- 240V AC voltage rating
- Bolt-on mounting
- 10kA interrupt rating at 240V
- Multi9 MG series
- D-curve trip unit
- UL listed
- CSA certified
- Thermal magnetic protection
- Padlockable
- Tunnel type terminals
Specifications
- Part Number: MG24500
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : MG
- Voltage : 240
- Amperage : 1
- Phase : 1
- Poles : 1
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- GTIN : 00785901880950
- Dimensions : 3.2 in (81 mm) x 0.7 in (18 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.27
