Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
24500
MG24500 is a single-pole miniature circuit breaker from Schneider Electric's Multi9 C60 series, designed for DIN rail mounting and rated for 1 amp at 277 volts with a D curve trip unit. This breaker is engineered for reliable protection in commercial and industrial applications where precise overcurrent protection is required. The MG24500 features a thermal magnetic trip mechanism, DIN rail mounting, and is suitable for use in control panels and distribution boards. It is UL listed and CSA certified, ensuring compliance with North American safety standards. The breaker is designed for 50/60 Hz operation and offers an interrupt rating of 5 kA at 277 VAC.
- Part Number: MG24500
- Manufacturer: Schneider Electric
- Series: Multi9 C60
- Number of Poles: 1
- Amperage Rating: 1 A
- Voltage Rating: 277 VAC
- Mounting Type: DIN Rail
- Interrupt Rating: 5 kA @ 277 VAC
- Frequency: 50/60 Hz
- Curve Type: D Curve
- Protection Type: Thermal Magnetic
- Certifications: UL Listed, CSA Certified
Specifications
- Part Number: 24500
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : 245
- Voltage : 277
- Amperage : 1
- Phase : 1
- Poles : 1
- AIC rating : 5kA@277V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 746071245000
- GTIN : 00746071245000
- Dimensions : Height 3.19 in (81 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 3.95
