Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
24545
24545 is a Schneider Electric Multi9 series circuit breaker rated for 50 amps and 480 volts with 3 poles.
This circuit breaker features a thermal-magnetic trip unit with a D curve characteristic, designed for reliable protection in electrical distribution systems. It has a 5 kA interrupting rating at 480 volts and is suitable for DIN rail mounting. The breaker complies with UL1077 standards and is part of the Multi9 family, known for compact and efficient circuit protection.
- Key Specifications
- Amperage: 50 A
- Voltage: 480 V
- Poles: 3
- Interrupt Rating: 5 kA @ 480 V
- Series/Frame: Multi9
- Trip Unit: Thermal-magnetic, D curve
- Mounting Type: DIN rail
- Certifications: UL1077
- Part Number: 24545
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : 245
- Voltage : 480
- Amperage : 50
- Phase : 3
- Poles : 3
- AIC rating : 5kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
- UPC : 073141301499
- GTIN : 00731413014994
- Dimensions : Height 3.19 in (81 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 12.97
