MG24471 - Schneider Electric 32A 3-Pole DIN Rail Mount Miniature Circuit Breaker

MG24471

MG24471 is a 32A, 3-pole miniature circuit breaker designed for DIN rail mounting, offering reliable protection for electrical circuits. This breaker is part of the Multi9 family and features a thermal magnetic trip unit for dependable circuit protection. The MG24471 is engineered for use in a variety of industrial and commercial applications, providing robust performance in a compact design. Its DIN rail mounting allows for easy installation in control panels and distribution boards, while the thermal magnetic trip mechanism ensures fast response to both overload and short-circuit conditions.

• 32A rated current
• 3-pole configuration
• DIN rail mount
• Miniature circuit breaker
• Thermal magnetic trip unit
• Multiple breaking capacity ratings
• 14-2 AWG copper wire compatible
• Multi9 series
• UL1077 listed
• EN/IEC 60947-2 compliant
• 50/60 Hz frequency
• C curve trip characteristic

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: MG24471
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Multi9
• Type : MG
• Voltage : 240
• Amperage : 32
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 2 AWG
• Protection : Thermal Magnetic

Product Data

• UPC : 785901346555
• Country of Origin : France
• Dimensions : 3.2 in (81 mm) x 2.1 in (54 mm) x 2.9 in (73 mm) (Height x Width x Depth)
• Weight : 0.82
• Standards : UL 1077, CE, CSA, IEC
• Certification : UL, CSA, CE, IEC, EN, IEC, GB, UR, CCC
