Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG24453
MG24453 is a 2 pole, 25 amp, 240 volt bolt-on circuit breaker from Square D's Multi9 series designed for reliable circuit protection.This thermal magnetic circuit breaker features a C curve trip unit, suitable for general purpose applications. It has a 10kA interrupting rating at 240 volts AC and is UL listed and CSA certified. The bolt-on mounting type ensures secure installation in compatible panels.
- Key Specifications
- Amperage: 25 Amp
- Voltage: 240 Volt AC
- Number of Poles: 2
- Mounting Type: Bolt-On
- Interrupt Rating: 10kA @ 240V AC
- Series/Frame: Multi9 (MG)
- Trip Unit: Thermal Magnetic, C Curve
- Certifications: UL Listed, CSA Certified
- Part Number: MG24453
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : MG
- Voltage : 240
- Amperage : 25
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
- Dimensions : 3.2 in (81 mm) x 1.4 in (36 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.52
