Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG24444
MG24444 is a Schneider Electric Multi9 C60 UL1077 miniature circuit breaker designed for reliable overcurrent protection.This 2 pole, 3 amp circuit breaker features a C curve trip characteristic and is rated for 240 volts AC with a 10kA interrupting capacity. It is part of the Multi9 MG series and provides thermal magnetic protection suitable for various electrical applications.
- Manufacturer: Schneider Electric
- Series: Multi9 MG
- Type: Miniature Circuit Breaker (MCB)
- Poles: 2
- Current Rating: 3 Amps
- Voltage Rating: 240 VAC
- Trip Curve: C Curve (thermal magnetic)
- Interrupt Rating: 10 kA at 240V
- Mounting Type: Din Rail Clip-On
- Device Short Name: C60 UL1077
Specifications
- Part Number: MG24444
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : MG
- Voltage : 240
- Amperage : 3
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- Dimensions : 3.2 in (81 mm) x 1.4 in (36 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.52
- Certification : UL, CSA, EN, IEC, CCC, GB, UR
