Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG24431
MG24431 is a single-pole miniature circuit breaker from Schneider Electric's Multi9 C60 UL1077 series, designed for reliable protection in commercial and industrial applications. This breaker features a C curve trip unit and is suitable for use with both AC and DC circuits. The MG24431 offers a rated current of 8A and a maximum operational voltage of 277V AC, with a breaking capacity of 10kA at 240V AC. It is designed for DIN rail mounting and is certified to UL 1077 and CSA C22.2 No. 235 standards, making it ideal for supplementary protection in control panels and equipment.
- Part Number: MG24431
- Manufacturer: Schneider Electric
- Series: Multi9 C60 UL1077
- Poles: 1P
- Rated Current: 8A
- Rated Voltage: 277V AC
- Mounting Type: DIN Rail
- Interrupt Rating: 10kA at 240V AC
- Breaker Curve: C Curve
- Trip Unit: Thermal-Magnetic
- Certifications: UL 1077, CSA C22.2 No. 235
- Standards: EN/IEC 60947-2, GB 14048.2
Specifications
- Part Number: MG24431
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : MG
- Voltage : 240
- Amperage : 8
- Phase : 1
- Poles : 1
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Dimensions : 3.2 in (81 mm) x 0.7 in (18 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.27
