Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG24139
MG24139 is a Schneider Electric Multi9 C60 series 2-pole circuit breaker rated for 63 amps and designed for use in AC and DC applications.
This molded case circuit breaker features a B curve trip unit and supports voltages of 480Y/277 VAC and 125 VDC. It offers an interrupt rating of 5 kA at 480Y/277 VAC and complies with IEC/EN 60947-2 standards. The breaker is DIN rail mountable and suitable for supplementary protection in electrical distribution systems.
- Key Specifications
- Amperage: 63 A
- Voltage Rating: 480Y/277 VAC, 125 VDC
- Poles: 2
- Series/Frame: Multi9 C60
- Trip Unit: B Curve
- Interrupt Rating: 5 kA at 480Y/277 VAC
- Mounting Type: DIN Rail
- Standards: IEC/EN 60947-2
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: MG24139
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : MG
- Voltage : 240
- Amperage : 63
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Country of Origin : France
- Dimensions : 3.2 in (81 mm) x 1.4 in (36 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.57
