MG24136 - Square D 32A 2-Pole Mini Multi9 Circuit Breaker, 240VAC, B-Curve, DIN Mount

MG24136

MG24136 is a Square D Mini Multi9 circuit breaker designed for reliable circuit protection with 32 amps and 2 poles.This circuit breaker features a 32A amperage rating, 2 poles, and a B-curve trip characteristic suitable for general-purpose protection. It is rated for 240VAC operation with an interrupting rating of 10kA. The breaker is designed for DIN rail mounting and is part of the Mini Multi9 series by Square D (Schneider Electric). It offers compact size with a width of approximately 1.42 inches and is suitable for use in residential, commercial, and light industrial applications.

Key Specifications
• Amperage: 32A
• Voltage: 240VAC
• Poles: 2
• Trip Curve: B-Curve
• Interrupt Rating: 10kA
• Mounting Type: DIN Rail
• Series/Frame: Mini Multi9
• Width: 1.42 inches
• Manufacturer: Square D (Schneider Electric)
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: MG24136
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 240
• Amperage : 32
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic



Product Data

• Dimensions : 3.2 in (81 mm) x 1.4 in (36 mm) x 2.9 in (73 mm) (Height x Width x Depth)
• Weight : 0.56
