MG24133 - Schneider Electric Multi9 C60 2-Pole 16 Amp 480Y/277V Circuit Breaker

MG24133

MG24133 is a 2-pole molded case circuit breaker from Schneider Electric designed for industrial and commercial power distribution applications.

The MG24133 is part of the Multi9 C60 series and features a B-curve trip characteristic suitable for general-purpose circuits. It operates at 480Y/277 volts and provides 16 amperes of protection. The breaker includes tunnel-type terminals that accept wire sizes from AWG 14 to AWG 4 (2.5 to 25 mm²) and is padlockable for safety compliance. With a 5 kA interrupt rating and UL1077 certification, this miniature circuit breaker delivers reliable performance in demanding electrical environments.

• Part Number: MG24133
• Manufacturer: Schneider Electric
• Series: Multi9 C60
• Poles: 2
• Amperage: 16 A
• Voltage: 480Y/277 V
• Trip Curve: B Curve
• Interrupt Rating: 5 kA
• Terminal Type: Tunnel Type (Top or Bottom)
• Wire Range: AWG 14 to AWG 4
• Certification: UL1077
• Padlockable: Yes

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: MG24133
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Multi9
• Type : MG
• Voltage : 240
• Amperage : 16
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : France
• Dimensions : 3.2 in (81 mm) x 1.4 in (36 mm) x 2.9 in (73 mm) (Height x Width x Depth)
• Weight : 0.51
• Certification : UL, CSA, EN, IEC, CCC, GB, UR
