Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MG17446
MG17446 is a Schneider Electric 2-pole miniature circuit breaker with a 15 amp rating and C curve trip characteristic designed for DIN rail mounting.
This circuit breaker features thermal magnetic trip units and is rated for 480Y/277 volts AC operation. It complies with UL1077 standards and offers a 5kA interrupt rating at 480 volts, suitable for supplementary protection in control panels and electrical distribution systems.
- Key Specifications
- Amperage: 15 A
- Voltage Rating: 480Y/277 VAC
- Number of Poles: 2
- Trip Type: Thermal Magnetic, C Curve
- Mounting Type: DIN Rail
- Interrupt Rating: 5 kA at 480 V
- Series/Frame: Multi 9™ C60 UL1077
- Certification: UL1077
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: MG17446
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : MG
- Voltage : 240
- Amperage : 15
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- GTIN : 00785901889502
- Dimensions : 3.2 in (81 mm) x 1.4 in (36 mm) x 2.9 in (73 mm) (Height x Width x Depth)
- Weight : 0.52
- Certification : UR, CSA, CCC, IEC, UL, EN, GB
- Wire Size : AWG 14 to AWG 4
