MDL3800 - Cutler Hammer 800A 600V 3-Pole MDL Frame Molded Case Circuit Breaker

MDL3800

MDL3800 is a Cutler Hammer molded case circuit breaker designed for reliable power distribution protection.This 3-pole, 800 ampere, 600 VAC rated breaker features a thermal magnetic trip unit with interchangeable long-time and instantaneous trip functions. It belongs to the MDL frame, Series C, and supports feed-thru mounting with line and load side lug terminals. The breaker offers a high interrupt rating of 65 kA at 240 VAC and 50 kA at 480 VAC, meeting UL and CSA certifications for safety and performance.

Key Specifications
• Amperage: 800 A
• Voltage: 600 VAC, 250 VDC
• Poles: 3
• Frame: MDL
• Series: Series C
• Trip Type: Thermal Magnetic, Interchangeable Long-Time and Instantaneous
• Interrupt Rating: 65 kA at 240 VAC, 50 kA at 480 VAC
• Mounting Type: Feed-Thru
• Terminals: Line and Load Side Lug
• Certifications: UL Listed, CSA Certified
• Dimensions: Approx. 10.75" x 10.75" x 10.75"
• Weight: Approx. 30 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: MDL3800
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : MDL
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 50kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Line/Load Lug
• Frame Size : 800A/M
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 400 MCM Max. Wire Size 3 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 782114586006
• GTIN : 00782114586006
• Country of Origin : United States
• Dimensions : 18 in x 8 in x 11 in (Length/Depth x Height x Width)
• Weight : 30 lb
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
