Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
MD63B700
MD63B700 is a Siemens 3 pole molded case circuit breaker rated for 700 amps and 600 volts AC, designed for reliable thermal magnetic protection.This MD frame breaker features a bolt-on mounting type with long-time and instantaneous trip functions, thermal magnetic trip unit, and load side lug terminals. It has an interrupting rating of 100kA at 240VAC and is suitable for 3-phase applications.
- Amperage: 700A
- Voltage: 600V AC
- Poles: 3
- Frame Type: MD
- Mounting Type: Bolt-On
- Interrupting Rating: 100kA at 240VAC
- Trip Unit: Thermal Magnetic, Interchangeable
- Connection: Load Side Lug Terminals
- Phase: 3
- Functions: Long-Time and Instantaneous Trip
- Voltage DC Rating: 500V DC
- Certifications: UL Listed
Specifications
- Part Number: MD63B700
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : MD
- Voltage : 600
- Amperage : 700
- Phase : 3
- Poles : 3
- AIC rating : 50kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : MD Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 783643214477
- GTIN : 00783643214477
- Country of Origin : Mexico
- Weight : 0.022
