Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
LXD62L600
LXD62L600 is a Siemens LD frame molded case circuit breaker designed for industrial power distribution applications. This 2-pole breaker features a 600 ampere continuous current rating at 600 volts AC, with adjustable magnetic trip protection and thermal-magnetic trip characteristics. The breaker incorporates a push-to-trip button for manual operation and is equipped with line and load lugs for direct connection to power systems.
- Frame Type: LD
- Poles: 2
- Amperage: 600A
- Voltage: 600 VAC
- Voltage DC: 250 VDC
- Trip Unit: Adjustable Magnetic
- Trip Setting: 2000 to 4000 Amperes
- Interrupt Rating: 25 kA
- Connection: Bolt-On with Line and Load Lugs
- Mounting: Molded Case
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: LXD62L600
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : LXD
- Voltage : 600
- Amperage : 600
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : I - Instantaneous
- Frame Size : LD Frame
- Temp Rating : -13¡F-158¡F
- Protection : Magnetic Only
Product Data
- UPC : 783643214293
- GTIN : 00783643214293
- Country of Origin : Mexico
- Dimensions : 8.661 x 12.992 x 6.700
- Weight : 15.201
- Certification : Ul Listed
