Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Under Voltage Release
Description
LV429408
LV429408 is an undervoltage release accessory designed for Schneider Electric Compact NSX circuit breakers, providing reliable remote opening and emergency off functionality.This undervoltage release operates at a rated voltage range of 380 to 415 VAC at 50/60 Hz or 440 to 480 VAC at 60 Hz. It features screwless spring terminal connections and a fixed mounting type. The device activates to open the circuit breaker if the control voltage drops below 35% of its nominal voltage, ensuring enhanced protection and safety.
- Rated voltage: 380-415 VAC 50/60 Hz, 440-480 VAC 60 Hz
- Mounting type: Fixed
- Connection type: Screwless spring terminals
- Response time: 50 ms
- Supply holding power: 5 W
- Supply inrush power: 30 W
- Compatible with Compact NSX 100 to 630 frame circuit breakers
- Used for emergency off or remote opening applications
Specifications
- Part Number: LV429408
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Under Voltage Release
- Family : Compact
- Type : LV4
- Control Voltage Minimum : 380
- Compatible Frames : NS,NSF,NSX,NFNF,NFHF,NFNL,NFHL,NSJ,NJNF,NJNL,NJHF,NJHL
- Control Voltate Maximum : 415
Product Data
- GTIN : 03606480018978
- Country of Origin : Poland
- Dimensions : Depth 5.38 in (136.65 mm) x Width 5.64 in (143.26 mm)
- Weight : 0.247
