Description
LMD63T700
LMD63T700 is a Siemens 3 pole circuit breaker trip unit rated for 700 amps and 600 volts AC, designed for reliable power distribution protection.This trip unit fits the LMD frame series and provides thermal magnetic protection with a 50kA interrupting rating at 480V. It is engineered for bolt-on mounting and suitable for industrial and commercial electrical applications requiring robust circuit interruption.
- Key Specifications
- Amperage: 700A trip rating
- Voltage: 600V AC
- Poles: 3
- Frame Type: LMD Trip Unit
- Interrupt Rating: 50kA at 480V
- Trip Unit Type: Thermal Magnetic
- Mounting Type: Bolt-On
- Voltage Type: AC
- Certifications: UL Listed (typical for Siemens breakers)
- UPC: 783643268166
- Part Number: LMD63T700
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : LMD
- Voltage : 600
- Amperage : 700
- Phase : 3
- Poles : 3
- AIC rating : 50kA@480V
- Connection : Bolt-On
- Functions : LI - Long Time and Instantaneous Trip
- Amperage Maximum : 700
- Protection : Thermal Magnetic
- Compatible Frames : LMD,HLMD
- UPC : 783643268166
- GTIN : 00783643268166
- Country of Origin : Mexico
- Weight : 2.639
- Wire Size : AWG 1/0 to 500KCM, Cu/Al
