Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
LHL36200V
LHL36200V is a Square D molded case circuit breaker designed for industrial and commercial power distribution applications.LHL36200V is a 3 pole, 200 amp rated circuit breaker with a maximum voltage rating of 600 volts. It belongs to the LHL Series and features thermal magnetic trip units with long-time and instantaneous trip functions. This breaker offers a high interrupting capacity of 35kA at 480V and is designed for feed-thru mounting.
- Manufacturer: Square D
- Series: LHL
- Amperage: 200A
- Voltage Rating: 600V
- Poles: 3
- Interrupt Rating: 35kA at 480V
- Trip Unit: Thermal Magnetic with Long-Time and Instantaneous
- Mounting Type: Feed-Thru
- Dimensions: Approx. 11 in height, 6 in width, 5.84 in depth
Specifications
- Part Number: LHL36200V
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LHL Series
- Type : LHL
- Voltage : 600
- Amperage : 200
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Dimensions : Depth 17.75 in (450.85 mm) Width 36.62 in (930.15 mm) Height 69.13 in (1755.90 mm)
- Weight : 20
