Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
LDB2300W
LDB2300W is a Series C L-frame molded case circuit breaker from Eaton, designed for reliable protection in commercial and industrial applications. This two-pole breaker features a fixed thermal and fixed magnetic trip unit, providing consistent overcurrent protection for electrical systems. The breaker is rated for 300 amps and is suitable for use in 240V and 480V systems, with a high interrupt rating for demanding environments. It is supplied without terminals and is compatible with a wide range of accessories for flexible installation.This Eaton Series C molded case circuit breaker is built for durability and performance, with a robust L-frame design and a proven track record in the field. The fixed thermal and fixed magnetic trip unit ensures reliable operation, while the two-pole configuration supports a variety of circuit protection needs. The breaker is rated for 50/60 Hz operation and is certified to UL 489 standards.
- Part Number: LDB2300W
- Manufacturer: Eaton
- Series: Series C
- Frame Type: L-Frame
- Amperage: 300A
- Poles: 2
- Interrupt Rating: 65 kAIC at 240V, 35 kAIC at 480V
- Mounting Type: Without terminals
- Frequency: 50/60 Hz
- Trip Unit: Fixed thermal, fixed magnetic
- Certifications: UL 489
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: LDB2300W
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : LDB
- Voltage : 600
- Amperage : 300
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679148433
- GTIN : 00786679148433
- Country of Origin : United States
- Dimensions : 4.06 in x 8.25 in x 8.25 in (Length/Depth x Height x Width)
- Weight : 18
- Certification : UL 489
