Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
LAL26225V
LAL26225V is a 2-pole molded case circuit breaker from Square D designed for reliable circuit protection in commercial and industrial applications.This circuit breaker features a 225 ampere current rating and supports voltages up to 600VAC and 250VDC. It uses a thermal magnetic trip unit with long time and instantaneous trip functions for precise protection. The breaker has a unit mount type with line and load side lug terminals and a 22kA interrupting rating at 600VAC and 10kA at 250VDC. It is part of the LAL frame series and is HACR rated for HVAC applications.
- Manufacturer: Square D
- Amperage: 225A
- Voltage Rating: 600VAC, 250VDC
- Poles: 2
- Mounting Type: Unit Mount
- Interrupting Rating: 22kA at 600VAC, 10kA at 250VDC
- Frame Type: LAL
- Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
- Terminals: Line and Load Side Lugs
- HACR Rated
Specifications
- Part Number: LAL26225V
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LAL Series
- Type : LAL
- Voltage : 600
- Amperage : 225
- Phase : 1
- Poles : 2
- AIC rating : 30kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 18
