JLA36150 - Square D Powerpact J-Frame 3P 150A 600V Thermal Magnetic Molded Case Circuit Breaker I-Line Plug-In

JLA36150

JLA36150 is a Square D Powerpact J-Frame 3-pole molded case circuit breaker designed for reliable overload and short-circuit protection in commercial and industrial power distribution systems. This breaker features a thermal-magnetic trip unit, I-Line plug-in mounting, and is suitable for reverse fed applications with a non-interchangeable trip. It is UL listed and built to meet rigorous safety standards for dependable performance. Engineered for use in Powerpact panelboards, the JLA36150 offers a continuous current rating of 150A at 600V AC, with an interrupting rating of 100kA at 480V and 50kA at 600V. The breaker is compatible with copper and aluminum conductors from AWG 4 to 4/0, and features a toggle control type for easy operation. Its compact design and robust construction make it ideal for demanding environments.

• Part Number: JLA36150
• Manufacturer: Square D
• Series/Frame: Powerpact J-Frame
• Poles: 3
• Amperage: 150A
• Voltage: 600V AC
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 100kA @ 480V, 50kA @ 600V
• Protection Type: Thermal Magnetic
• Phase: 3-Phase
• Standards: UL 489 Listed
• Terminal Size: AWG 4 to 4/0 Copper/Aluminum

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JLA36150
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JLA
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : I-Line, Lug
• Frame Size : L
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 3/0 AWG (Cu/Al) Max. Wire Size 350 kcmil (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901700722
• GTIN : 00785901700722
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 7.2
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 4...AWG 4/0 aluminium/copper terminal
