JJA262252 - Square D 225A 2-Pole 600V PowerPact J-Frame Circuit Breaker

JJA262252

JJA262252 is a 225 amp, 2-pole circuit breaker designed for 600 Volt applications from Square D.JJA262252 is a PowerPact J-Frame thermal magnetic circuit breaker with a current limiting design, suitable for use in I-Line panelboards and switchboards. It features a 25 kA interrupt rating at 600 VAC and is UL, CSA, and CE certified.

• Amperage: 225 A
• Voltage Rating: 600 V AC
• Poles: 2
• Interrupt Rating: 25 kA at 600 VAC
• Frame Type: PowerPact J-Frame
• Trip Unit: Thermal Magnetic
• Mounting Type: I-Line
• Certifications: UL Listed, CSA, CE

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JJA262252
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JJA
• Voltage : 600
• Amperage : 225
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901939221
• GTIN : 00785901939221
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
