Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
JGS3225FAG
JGS3225FAG is a Cutler Hammer molded case circuit breaker rated for 225 amps, 600 volts, and three poles with a JG frame and thermal magnetic trip unit.This circuit breaker features adjustable magnetic and fixed thermal trip functions, line/load side lug terminals, and a high interrupt rating suitable for industrial applications. It supports 85 kAIC at 240V, 40 kAIC at 415V, 35 kAIC at 480V, and 18 kAIC at 600V, ensuring reliable protection and compliance with industry standards.
- Key Specifications
- Manufacturer: Cutler Hammer (Eaton)
- Amperage: 225A
- Voltage: 600 VAC
- Poles: 3
- Frame Type: JG
- Interrupt Rating: 85 kA at 240V, 40 kA at 415V, 35 kA at 480V, 18 kA at 600V
- Trip Unit: Thermal Magnetic (adjustable magnetic, fixed thermal)
- Mounting: Line/load side standard with metric hardware
- Certifications: Meets industry standards for molded case circuit breakers
- Part Number: JGS3225FAG
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : JGS
- Voltage : 600
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
- UPC : 782113526812
- GTIN : 00782113526812
- Country of Origin : Dominican Republic
- Dimensions : 3.57 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 6
- Certification : CSA Certified,IEC Rated,UL Listed,CE Marked
