JGP36250U31X - Square D 250A 3-Pole 600VAC Circuit Breaker

JGP36250U31X

JGP36250U31X is a 3-pole molded case circuit breaker from Square D designed to protect electrical systems from overloads and short circuits in industrial and commercial applications. This PowerPacT J-Frame breaker delivers reliable performance with electronic tripping and current-limiting capabilities for demanding power distribution environments. Key Specifications

• Amperage: 250 Amps
• Voltage: 600VAC
• Poles: 3
• Frame Type: JGP PowerPacT J-Frame
• Tripping Mechanism: Electronic with Micrologic 3.2
• Trip Unit: Adjustable, Current Limiting
• Interrupt Rating: 35kAIC at 480V
• Terminal Connection: Lug
• Mount Type: Panel Mount, Bolt-On
• Width: 4.09 inches
• Depth: 3.39 inches
• Height: 7.52 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGP36250U31X
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JGP
• Voltage : 600
• Amperage : 250
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : J Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Solid State

Product Data

• UPC : 060648628326
• GTIN : 03606486283264
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.18
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
