JGL36175C - Square D 175A 600V 3-Pole PowerPact J-Frame Circuit Breaker Thermal-Magnetic

JGL36175C

JGL36175C is a Square D PowerPact J-Frame circuit breaker rated for 175 amps, 600 volts, and 3 poles with thermal-magnetic trip technology.This molded case circuit breaker features a 3-pole configuration designed for unit mount applications. It supports a rated operational voltage of up to 600 VAC and 500 VDC, with a breaking capacity of 65 kA at 240 VAC, 35 kA at 480 VAC, and 18 kA at 600 VAC. The breaker uses lugs for both line and load connections and accommodates AWG 4 to 4/0 aluminum or copper conductors. It is UL 489 listed and designed for reliable protection in industrial and commercial power distribution systems.

Key Specifications
• Amperage: 175 A
• Voltage Rating: 600 VAC / 500 VDC
• Number of Poles: 3 (3P)
• Frame/Series: PowerPact J-Frame
• Trip Unit: Thermal-magnetic
• Interrupt Rating: 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 20 kA at 500 VDC
• Mounting Type: Unit mount
• Electrical Connection: Lugs (line and load)
• AWG Range: 4 to 4/0 aluminum/copper
• Certifications: UL 489 Listed
• Dimensions: 7.52 in H x 4.12 in W x 5 in D
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: JGL36175C
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JGL
• Voltage : 600
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : J
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 4 AWG (Cu/Al) Max. Wire Size 4/0 AWG (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : CBA



Product Data

• UPC : 785901583226
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 4...AWG 4/0 aluminium/copper terminal
