Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
JGL26200LU
JGL26200LU is a Square D PowerPact J Frame molded case circuit breaker rated for 200 amps and 600 volts AC with 2 poles and lug connections.This circuit breaker features a thermal-magnetic trip unit, a breaking capacity of 18kA at 600VAC, and is designed for unit mount applications. It supports continuous current rating at 80% and complies with UL 489 standards. The breaker is suitable for use in industrial and commercial electrical distribution systems requiring reliable overcurrent protection.
- Manufacturer: Square D
- Part Number: JGL26200LU
- Amperage: 200A
- Voltage Rating: 600VAC
- Poles: 2
- Frame/Series: PowerPact J
- Trip Unit: Thermal-Magnetic
- Interrupt Rating: 18kA at 600VAC
- Mounting Type: Unit Mount
- UL 489 Listed
- Connection Type: Lugs
Specifications
- Part Number: JGL26200LU
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Temp Rating : 28-158 °F (-2-70 °C)
Product Data
- UPC : 078590192804
- Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
- Weight : 4.641
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
